Download our detailed brochure to explore specifications, features, and applications of PVC Belt Conveyors
Efficient Conveying with Extra Grip & Stability
Cleated Modular Belt Conveyors are designed for moving products on steep inclines, declines, or in applications where items need to stay in place during transfer. The modular interlocking belt combined with cleats (flights) provides excellent grip and prevents rollback, making it ideal for transporting loose, small, or packaged goods safely and efficiently.
Key Features:
- Modular plastic belt with cleats for superior grip
- Prevents product slippage on steep inclines/declines
- High load-carrying capacity with smooth, stable operation
- Easy-to-clean design, suitable for food-grade applications
- Corrosion-resistant and durable construction
- Quick and easy belt replacement system
- Customizable in cleat height, belt width, and conveyor length
- Low maintenance and long service life
Technical Specifications:
| Specification | Description |
|---|---|
| Belt Type | Modular Plastic Belt (PP/PE/Acetal – food-grade options available) |
| Cleat Height | 25 mm – 75 mm (customizable) |
| Belt Width | 300 mm – 1200 mm (as per requirement) |
| Conveyor Length | 1 meter – 20 meters |
| Incline/Decline Angle | Up to 60° (depending on design) |
| Frame Structure | Stainless Steel (SS304/SS316) / Mild Steel powder-coated |
| Drive System | Motorized with geared motor & VFD control |
| Belt Speed | 0.1 m/s – 2.5 m/s (adjustable) |
| Load Capacity | Up to 100 kg per meter |
| Temperature Range | -20°C to +90°C (depending on belt type) |
| Power Supply | 220V/380V, Single Phase or Three Phase |
Applications
- Food & Beverage Industry
- Pharmaceutical & Healthcare
- Warehousing & Logistics
- Electronics & Assembly Lines
- Printing & Packaging Units
- Agriculture & Manufacturing
